Rapid Fittings
SERIES: Rapid Fittings
Rapid Fittings
FEATURES
| The rapid fittings can be used with rigid nylon tubes.A Iocking nut is provided and can be tightened both manually and With a spanner.The special shape of the guiding cone ensures that the tube can not be accidentally cut. |
Specification
|
Material
|
Body and collet:Nickel-plated Brass O-ring:NBR(other material is available on request)
|
|
Threads
|
BSPT,BSPP,NPT,Metric threads
|
|
Pressure
|
0.8-16bar(see tube)PU,PE,Nylon 6-11-12
|
|
Fiuid
|
Compressed air
|
|
Temperature
|
-10 ~60℃ (see data of used tubing)
|
Other info
